AKAI 4000DS
Stereo Reel to Reel Tape Recorder (1973-79)
Specifications
| €250 | ||
| Track system: 4-track, 2-channel, stereo/monaural system | ||
| Heads: 1 x record, 1 x playback, 1 x erase | ||
| Motor: 1 x SSM-1 4-pole induction | ||
| Reel size: up to 7 inch reel | ||
| Tape speeds: 3 3⁄4 7 1⁄2 ips | ||
| Wow and flutter: 0.15% (7 1⁄2 ips) | ||
| Frequency response: 30Hz to 23kHz (7 1⁄2 ips) | ||
| Signal to Noise Ratio: 50dB | ||
| Total harmonic distortion: 1.5% | ||
| Crosstalk: 50dB | ||
| Input: 70mV (line), 7mV (DIN), 0.8mV (mic) | ||
| Output: 1.228V (line), 0.4V (DIN) | ||
| Semiconductors: 11 x transistors, 4 x IC, 4 x diodes | ||
| Dimensions: 406 x 314 x 194mm | ||
| Weight: 11.4kg | ||
| The Akai 4000DS is a four-track, two-channel stereo reel to reel tape recorder for use with 7" reels. The employment of a highly efficient induction motor and boldly designed flywheel in the 4000DS results in stable tape travel and reduced wow and flutter. This feature coupled with a three head system including Akai's one-micron gap playback head assures clear playback sound. |
